How to Identify Performance Bottlenecks
and Solving Them with the Ruleset Engine

Erfi Anugrah

Overview

What we’ll cover:

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#ff9800',
    'primaryTextColor': '#fff',
    'primaryBorderColor': '#fff',
    'lineColor': '#fff',
    'secondaryColor': '#006064',
    'tertiaryColor': '#4caf50',
    'mainBkg': '#2d3436',
    'nodeBorder': '#ff9800',
    'clusterBkg': '#2d3436',
    'clusterBorder': '#ff9800'
  },
  'themeCSS': '.edgePath path { stroke: #fff !important; }'
}}%%
graph TB
    Start[Key Performance Metrics] --> Bottlenecks[Common Bottlenecks]
    Bottlenecks --> Analysis[Analysis Methodology]
    Analysis --> Data[GraphQL Data Collection]
    Data --> Troubleshoot[Troubleshooting Workflow]
    Troubleshoot --> Solution[Implementation Solutions]

    classDef orange fill:#ff9800,stroke:#fff,stroke-width:2px,color:#fff;
    classDef blue fill:#006064,stroke:#fff,stroke-width:2px,color:#fff;
    classDef green fill:#4caf50,stroke:#fff,stroke-width:2px,color:#fff;

    class Start,Bottlenecks orange;
    class Analysis,Data blue;
    class Troubleshoot,Solution green;

Key Performance Metrics

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#ff9800',  /* Orange for main nodes */
    'primaryTextColor': '#fff',
    'primaryBorderColor': '#fff',
    'lineColor': '#fff',        /* Ensure lines are white */
    'secondaryColor': '#006064',  /* Blue-green for Response Times */
    'tertiaryColor': '#4caf50',   /* Green for Geographic Distribution */
    'quaternaryColor': '#8e44ad', /* Purple for Resource Utilization */
    'mainBkg': '#2d3436',
    'nodeBorder': '#fff',
    'clusterBkg': '#2d3436',
    'clusterBorder': '#fff'
  }
}}%%
graph LR
    Performance[Performance Metrics]
    Performance --> Response[Response Times]
    Performance --> Geographic[Geographic Distribution]
    Performance --> Resource[Resource Utilization]

    Response --> TTFB[Edge TTFB]
    Response --> Origin[Origin Response Time]
    Response --> Cache[Cache Performance]

    Geographic --> Latency[Regional Latency]
    Geographic --> Efficiency[Cache Efficiency]
    Geographic --> Errors[Error Distribution]

    Resource --> Load[Origin Load]
    Resource --> Bottlenecks[Application Bottlenecks]

    classDef orange fill:#ff9800,stroke:#fff,stroke-width:2px,color:#fff;
    classDef blue fill:#006064,stroke:#fff,stroke-width:2px,color:#fff;
    classDef green fill:#4caf50,stroke:#fff,stroke-width:2px,color:#fff;
    classDef purple fill:#8e44ad,stroke:#fff,stroke-width:2px,color:#fff;

    class Performance orange;
    class Response,TTFB,Origin,Cache blue;
    class Geographic,Latency,Efficiency,Errors green;
    class Resource,Load,Bottlenecks purple;

Common Performance Bottlenecks

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#ff9800',  /* Orange for main categories */
    'primaryTextColor': '#fff',
    'primaryBorderColor': '#fff',
    'lineColor': '#fff',        /* Ensure lines are white */
    'secondaryColor': '#4caf50',   /* Green for Cache Issues */
    'tertiaryColor': '#006064',    /* Blue for Network Problems */
    'quaternaryColor': '#8e44ad',  /* Purple for Origin Issues */
    'mainBkg': '#2d3436',
    'nodeBorder': '#fff',
    'clusterBkg': '#2d3436',
    'clusterBorder': '#fff'
  }
}}%%
graph TB
    Performance[Performance Bottlenecks]

    %% First Level
    Performance --> Cache[Cache Issues]
    Performance --> Network[Network Problems]
    Performance --> Origin[Origin Issues]

    %% Cache Issues (Compact Layout)
    Cache --> LowCache[Low Cache Hit Ratios]
    Cache --> TTL[Ineffective/Low TTLs]
    Cache --> Rules[Missing Cache Rules]
    Cache --> Design[Poor Cache Key Design]

    %% Network Problems (Compact Layout)
    Network --> Latency[High Origin Latency]
    Network --> Routing[Poor Routing Paths]
    Network --> Connectivity[Regional Connectivity]
    Network --> Limits[Connection Limits]

    %% Origin Issues (Compact Layout)
    Origin --> Overload[Server Overload]
    Origin --> Database[Database Bottlenecks]
    Origin --> Resources[Resource Exhaustion]
    Origin --> Timeouts[Timeout Configuration]

    %% Class Definitions
    classDef orange fill:#ff9800,stroke:#fff,stroke-width:2px,color:#fff;
    classDef green fill:#4caf50,stroke:#fff,stroke-width:2px,color:#fff;
    classDef blue fill:#006064,stroke:#fff,stroke-width:2px,color:#fff;
    classDef purple fill:#8e44ad,stroke:#fff,stroke-width:2px,color:#fff;

    class Performance orange;
    class Cache,LowCache,TTL,Rules,Design green;
    class Network,Latency,Routing,Connectivity,Limits blue;
    class Origin,Overload,Database,Resources,Timeouts purple;

Analysis Workflow

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#ff9800',
    'primaryTextColor': '#fff',
    'primaryBorderColor': '#fff',
    'lineColor': '#fff',
    'secondaryColor': '#006064',
    'tertiaryColor': '#4caf50',
    'mainBkg': '#2d3436',
    'nodeBorder': '#ff9800',
    'clusterBkg': '#2d3436',
    'clusterBorder': '#ff9800'
  }
}}%%
graph TB
    Start[Performance Issue] --> Identify{Identify Problem Type}
    Identify --> Cache[Cache Analysis]
    Identify --> Network[Network Analysis]
    Identify --> Origin[Origin Analysis]

    Cache --> CacheMetrics[Cache Metrics]
    Cache --> HitRatio[Hit Ratio]
    Cache --> CacheRules[Cache Rules]

    Network --> Latency[Latency Analysis]
    Network --> Routes[Route Analysis]
    Network --> Geo[Geographic Distribution]

    Origin --> Server[Server Metrics]
    Origin --> Database[Database Servers]
    Origin --> Application[Application Servers]

    CacheMetrics --> Solution{Solution}
    HitRatio --> Solution
    CacheRules --> Solution
    Latency --> Solution
    Geo --> Solution
    Routes --> Solution
    Server --> Solution
    Database --> Solution
    Application --> Solution

    classDef orange fill:#ff9800,stroke:#fff,stroke-width:2px,color:#fff;
    classDef blue fill:#006064,stroke:#fff,stroke-width:2px,color:#fff;
    classDef green fill:#4caf50,stroke:#fff,stroke-width:2px,color:#fff;

    class Start,Identify,Solution orange;
    class Cache,Network,Origin blue;
    class CacheMetrics,HitRatio,CacheRules,Latency,Routes,SSL,Server,Database,Application,Geo green;

Initial Investigation Steps

1. Baseline Metrics

Current cache hit ratio
Average response times
Quantiles for response times
Error rate patterns
Geographic distribution
Resource utilization

2. Impact Assessment

Affected regions
User experience impact
Origin load
Bandwidth implications

3. Root Cause Analysis

Timeline correlation
Configuration review
Log analysis
Performance profiling

GraphQL Demo

Performance analysis walkthrough
Common issue resolution
Implementation guidance

GraphQL Performance Analysis

query ZoneMetricsBasic($zoneTag: String!, $filter: ZoneHttpRequestsAdaptiveGroupsFilter!) {
  viewer {
    zones(filter: { zoneTag: $zoneTag }) {
      httpRequestsAdaptiveGroups(
        limit: 5000
        filter: $filter
        orderBy: [datetimeMinute_DESC]
      ) {
        dimensions {
          datetimeMinute
          clientCountryName
          clientDeviceType
          clientRequestHTTPProtocol
          edgeResponseContentTypeName
          edgeResponseStatus
          cacheStatus
          coloCode
          upperTierColoName
        }
        avg {
          sampleInterval
          edgeTimeToFirstByteMs
          originResponseDurationMs
        }
        sum {
          visits
          edgeResponseBytes
        }
        count
        ratio {
          status4xx
          status5xx
        }
      }
    }
  }
}

query ZoneMetricsDetailed($zoneTag: String!, $filter: ZoneHttpRequestsAdaptiveGroupsFilter!) {
  viewer {
    zones(filter: { zoneTag: $zoneTag }) {
      httpRequestsAdaptiveGroups(
        limit: 5000
        filter: $filter
        orderBy: [datetimeMinute_DESC]
      ) {
        dimensions {
          datetimeMinute
          clientAsn
          clientIP
          clientRefererHost
          clientRequestHTTPHost
          clientRequestPath
          clientRequestHTTPMethodName
        }
        quantiles {
          edgeTimeToFirstByteMsP50
          edgeTimeToFirstByteMsP95
          edgeTimeToFirstByteMsP99
          originResponseDurationMsP50
          originResponseDurationMsP95
          originResponseDurationMsP99
        }
        sum {
          edgeTimeToFirstByteMs
          originResponseDurationMs
        }
      }
    }
  }
}

Take a Break ☕

Ruleset Engine with Terraform

Dashboard demo into rule building
Implementation guidance

Cache Optimization Solutions

1. Static Content Caching

resource "cloudflare_ruleset" "static_cache" {
  zone_id = var.zone_id
  name    = "Static Content Optimization"
  phase   = "http_request_cache_settings"

  rules {
    action = "set_cache_settings"
    action_parameters {
      cache = true
      edge_ttl {
        default = 31536000  # 1 year
        mode    = "override_origin"
      }
      browser_ttl {
        default = 86400    # 1 day
        mode    = "override_origin"
      }
      cache_key {
        custom_key {
          query_string {
            exclude = ["*"]  # Ignore all query params
          }
        }
      }
    }
    expression = "(http.request.uri.path matches \"\\.(jpg|jpeg|gif|png|ico|css|js|svg|woff2)$\")"
  }
}

2. API Response Caching

resource "cloudflare_ruleset" "api_cache" {
  zone_id = var.zone_id
  name    = "API Cache"
  phase   = "http_request_cache_settings"

  rules {
    action = "set_cache_settings"
    action_parameters {
      cache = true
      cache_key {
        custom_key {
          header {
            include = ["Authorization"]
          }
          query_string {
            include = ["version", "locale"]
          }
        }
      }
      edge_ttl {
        default = 300  # 5 minutes
        mode    = "respect_origin"
      }
      serve_stale {
        disable_stale_while_updating = false
      }
    }
    expression = "(http.host eq \"api.example.com\" and http.request.uri.path contains \"/v1/\")"
  }
}

Network Optimization

1. Argo Smart Routing

resource "cloudflare_argo" "argo" {
  zone_id        = var.cloudflare_zone_id
  smart_routing  = "on"
}

2. Tiered Cache

resource "cloudflare_tiered_cache" "tc" {
  zone_id        = var.cloudflare_zone_id
  cache_type     = "smart"
}

resource "cloudflare_regional_tiered_cache" "regional_tc" {
  zone_id        = var.cloudflare_zone_id
  value          = "on"
}

3. Load Balancing

resource "cloudflare_load_balancer" "revista" {
  default_pool_ids = [cloudflare_load_balancer_pool.revista_k3s_nl.id,  cloudflare_load_balancer_pool.revista_ipsec_k3s_nl.id]
  enabled          = true
  fallback_pool_id = cloudflare_load_balancer_pool.revista_sg.id
  name             = var.domain_name
  proxied          = true
  session_affinity = "none"
  steering_policy  = "geo"
  zone_id          = var.cloudflare_zone_id
  pop_pools {
    pop      = "AMS"
    pool_ids = [cloudflare_load_balancer_pool.revista_k3s_nl.id, cloudflare_load_balancer_pool.revista_ipsec_k3s_nl.id]
  }
  pop_pools {
    pop      = "SIN"
    pool_ids = [cloudflare_load_balancer_pool.revista_sg.id]
  }
  adaptive_routing {
    failover_across_pools = true
  }
  location_strategy {
    mode       = "pop"
    prefer_ecs = "proximity"
  }
  random_steering {
    default_weight = 1
  }
  session_affinity_attributes {
    samesite               = "Auto"
    secure                 = "Auto"
    zero_downtime_failover = "temporary"
  }
}

4. Regional Cache Configuration

resource "cloudflare_ruleset" "regional_cache" {
  zone_id = var.zone_id
  name    = "Regional Cache Settings"
  phase   = "http_request_cache_settings"

  rules {
    action = "set_cache_settings"
    action_parameters {
      cache = true
      cache_key {
        custom_key {
          user {
            geo = true
            device_type = true
          }
        }
      }
      edge_ttl {
        default = 3600
        mode    = "override_origin"
      }
    }
    expression = "(ip.src.country in {\"US\" \"CA\" \"GB\"} and http.request.uri.path contains \"/content/\")"
  }
}

Things to Look Out For

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#ff9800',  /* Orange for main categories */
    'primaryTextColor': '#fff',
    'primaryBorderColor': '#fff',
    'lineColor': '#fff',        /* Ensure lines are white */
    'secondaryColor': '#4caf50',   /* Green for Cache Optimization */
    'tertiaryColor': '#006064',    /* Blue for Network Optimization */
    'quaternaryColor': '#8e44ad',  /* Purple for Origin Optimization */
    'mainBkg': '#2d3436',
    'nodeBorder': '#fff',
    'clusterBkg': '#2d3436',
    'clusterBorder': '#fff'
  }
}}%%
graph TB
    Solutions[Optimization Solutions]

    %% Categories
    Solutions --> Cache[Cache Optimization]
    Solutions --> Network[Network Optimization]
    Solutions --> Origin[Origin Optimization]

    %% Cache Optimization (Compact Layout)
    Cache --> TTL[Appropriate TTLs]
    Cache --> Keys[Custom Cache Keys]
    Cache --> Tiered[Tiered Caching]

    %% Network Optimization (Compact Layout)
    Network --> Argo[Argo Smart Routing]
    Network --> Balancing[Load Balancing]
    Network --> Monitoring[Latency Monitoring]

    %% Origin Optimization (Compact Layout)
    Origin --> Errors[Error Handling]
    Origin --> Services[Service Monitoring]
    Origin --> Stale[Serve Stale Content]

    %% Class Definitions
    classDef orange fill:#ff9800,stroke:#fff,stroke-width:2px,color:#fff;
    classDef green fill:#4caf50,stroke:#fff,stroke-width:2px,color:#fff;
    classDef blue fill:#006064,stroke:#fff,stroke-width:2px,color:#fff;
    classDef purple fill:#8e44ad,stroke:#fff,stroke-width:2px,color:#fff;

    class Solutions orange;
    class Cache,TTL,Keys,Tiered green;
    class Network,Argo,Balancing,Monitoring blue;
    class Origin,Errors,Services,Stale purple;

How to Identify Performance Bottlenecks and Solving Them with the Ruleset Engine

Overview

Key Performance Metrics

Common Performance Bottlenecks

Analysis Workflow

Initial Investigation Steps

1. Baseline Metrics

2. Impact Assessment

3. Root Cause Analysis

GraphQL Demo

GraphQL Performance Analysis

Take a Break ☕

Ruleset Engine with Terraform

Cache Optimization Solutions

1. Static Content Caching

2. API Response Caching

Network Optimization

1. Argo Smart Routing

2. Tiered Cache

3. Load Balancing

4. Regional Cache Configuration

Things to Look Out For

Survey

How to Identify Performance Bottlenecks
and Solving Them with the Ruleset Engine
